hP5-NaZn1.5Ge0.5As2 (Inverse)

hP5–NaZn_1.5Ge_0.5As₂ (Inverse)

Image of hP5–NaZn_1.5Ge_0.5As₂ (Inverse), generated by Vesta

Lattice Vectors:

\[\begin{split}a_1 &= ~\hat{x}\\ a_2 &= -1/2~\hat{x} + \sqrt{3}/\sqrt{4}~\hat{y}\\ a_3 &= 1.8184771022~\hat{z}\\\end{split}\]

Space Group: 164

Point Group of Structure: \(\bar{3}m\)

Structure DOI: https://doi.org/10.1021/ic302627n

Source: Crystallographic Open Database #4334189

MPB Epsilon Input File: Download

Gap Atlas for \(\varepsilon = 16\)

Gap Atlas for \(\varepsilon\) = 16 across filling fraction \(\phi\) and frequency \(\omega\).

Gap Atlas for \(\varepsilon = 14\)

Gap Atlas for \(\varepsilon\) = 14 across filling fraction \(\phi\) and frequency \(\omega\).

Gap Atlas for \(\varepsilon = 12\)

Gap Atlas for \(\varepsilon\) = 12 across filling fraction \(\phi\) and frequency \(\omega\).

Gap Atlas for \(\varepsilon = 10\)

Gap Atlas for \(\varepsilon\) = 10 across filling fraction \(\phi\) and frequency \(\omega\).

Gap Atlas for \(\varepsilon = 8\)

Gap Atlas for \(\varepsilon\) = 8 across filling fraction \(\phi\) and frequency \(\omega\).

Gap between Bands 6-7

Below is the band structure and isosurface of hP5–NaZn_1.5Ge_0.5As₂ (Inverse) at dielectric contrast \(\varepsilon = 16\), radius \(r = 0.44\) and filling fraction \(\phi = 0.135\).

Band Structure across first Brillouin Zone.

View along \(a_1\).

View along \(a_2\).

Gap between Bands 18-19

Below is the band structure and isosurface of hP5–NaZn_1.5Ge_0.5As₂ (Inverse) at dielectric contrast \(\varepsilon = 16\), radius \(r = 0.41\) and filling fraction \(\phi = 0.222\).

Band Structure across first Brillouin Zone.

View along \(a_1\).

View along \(a_2\).
