mC336-SO2 (Inverse)

mC336–SO₂ (Inverse)

Image of mC336–SO₂ (Inverse), generated by Vesta

Lattice Vectors:

\[\begin{split}a_1 &= ~\hat{x}\\ a_2 &= 0.5900893446~\hat{y}\\ a_3 &= 0.1966237243~\hat{x} + 0.5099067863~\hat{z}\\\end{split}\]

Space Group: 12

Point Group of Structure: \(2/m\)

Structure DOI: https://doi.org/10.1021/ja00118a013

Source: Crystallographic Open Database #4114080

MPB Epsilon Input File: Download

Gap Atlas for \(\varepsilon = 16\)

Gap Atlas for \(\varepsilon\) = 16 across filling fraction \(\phi\) and frequency \(\omega\).

Gap Atlas for \(\varepsilon = 14\)

Gap Atlas for \(\varepsilon\) = 14 across filling fraction \(\phi\) and frequency \(\omega\).

Gap Atlas for \(\varepsilon = 12\)

Gap Atlas for \(\varepsilon\) = 12 across filling fraction \(\phi\) and frequency \(\omega\).

Gap Atlas for \(\varepsilon = 10\)

Gap Atlas for \(\varepsilon\) = 10 across filling fraction \(\phi\) and frequency \(\omega\).

Gap Atlas for \(\varepsilon = 8\)

Gap Atlas for \(\varepsilon\) = 8 across filling fraction \(\phi\) and frequency \(\omega\).

Gap Atlas for \(\varepsilon = 6\)

Gap Atlas for \(\varepsilon\) = 6 across filling fraction \(\phi\) and frequency \(\omega\).

Gap between Bands 4-5

Below is the band structure and isosurface of mC336–SO₂ (Inverse) at dielectric contrast \(\varepsilon = 16\), radius \(r = 0.12\) and filling fraction \(\phi = 0.189\).

Band Structure across first Brillouin Zone.

View along \(a_1\).
