oF8-BN (Direct)

oF8–BN (Direct)

Image of oF8–BN (Direct), generated by Vesta

Lattice Vectors:

\[\begin{split}a_1 &= 0.6110321016~\hat{y} + 0.7916058178~\hat{z}\\ a_2 &= 0.4559941187~\hat{x} + 0.7916058178~\hat{z}\\ a_3 &= 0.4559941187~\hat{x} + 0.6110321016~\hat{y}\\\end{split}\]

Space Group: 69

Point Group of Structure: \(mmm\)

Structure DOI: https://doi.org/10.17188/1284111

Source: Inorganic Crystallographic Database #20946

MPB Epsilon Input File: Download

Gap Atlas for \(\varepsilon = 16\)

Gap Atlas for \(\varepsilon\) = 16 across filling fraction \(\phi\) and frequency \(\omega\).

Gap Atlas for \(\varepsilon = 14\)

Gap Atlas for \(\varepsilon\) = 14 across filling fraction \(\phi\) and frequency \(\omega\).

Gap between Bands 8-9

Below is the band structure and isosurface of oF8–BN (Direct) at dielectric contrast \(\varepsilon = 16\), radius \(r = 0.25\) and filling fraction \(\phi = 0.263\).

Band Structure across first Brillouin Zone.

View along \(a_1\).
