tP38-D10SO8 (Direct)

tP38–D₁₀SO₈ (Direct)

Image of tP38–D₁₀SO₈ (Direct), generated by Vesta

Lattice Vectors:

\[\begin{split}a_1 &= ~\hat{x}\\ a_2 &= ~\hat{y}\\ a_3 &= 0.8491045537~\hat{z}\\\end{split}\]

Space Group: 114

Point Group of Structure: \(\bar{42}m\)

Structure DOI: https://doi.org/10.1107/S056774087200487X

Source: Crystallographic Open Database #2107424

MPB Epsilon Input File: Download

Gap Atlas for \(\varepsilon = 16\)

Gap Atlas for \(\varepsilon\) = 16 across filling fraction \(\phi\) and frequency \(\omega\).

Gap Atlas for \(\varepsilon = 14\)

Gap Atlas for \(\varepsilon\) = 14 across filling fraction \(\phi\) and frequency \(\omega\).

Gap Atlas for \(\varepsilon = 12\)

Gap Atlas for \(\varepsilon\) = 12 across filling fraction \(\phi\) and frequency \(\omega\).

Gap between Bands 10-11

Below is the band structure and isosurface of tP38–D₁₀SO₈ (Direct) at dielectric contrast \(\varepsilon = 16\), radius \(r = 0.125\) and filling fraction \(\phi = 0.305\).

Band Structure across first Brillouin Zone.

View along \(a_1\).
