oA12-SO2 (Inverse)

oA12–SO₂ (Inverse)

Image of oA12–SO₂ (Inverse), generated by Vesta

Lattice Vectors:

\[\begin{split}a_1 &= ~\hat{x}\\ a_2 &= 0.4892915889~\hat{y} + 0.5057660373~\hat{z}\\ a_3 &= -0.4892915889~\hat{y} + 0.5057660373~\hat{z}\\\end{split}\]

Space Group: 41

Point Group of Structure: \(mm2\)

Structure DOI: https://doi.org/10.1107/S0365110X5200109X

Source: Inorganic Crystallographic Database #24645

MPB Epsilon Input File: Download

Gap Atlas for \(\varepsilon = 16\)

Gap Atlas for \(\varepsilon\) = 16 across filling fraction \(\phi\) and frequency \(\omega\).

Gap Atlas for \(\varepsilon = 14\)

Gap Atlas for \(\varepsilon\) = 14 across filling fraction \(\phi\) and frequency \(\omega\).

Gap between Bands 16-17

Below is the band structure and isosurface of oA12–SO₂ (Inverse) at dielectric contrast \(\varepsilon = 16\), radius \(r = 0.26\) and filling fraction \(\phi = 0.327\).

Band Structure across first Brillouin Zone.

View along \(a_1\).
