hP3-Hg (Direct)

hP3–Hg (Direct)

Image of hP3–Hg (Direct), generated by Vesta

Lattice Vectors:

\[\begin{split}a_1 &= ~\hat{x}\\ a_2 &= 0.5865633199~\hat{y} + 1.0159574719~\hat{z}\\ a_3 &= -0.5865633199~\hat{y} + 1.0159574719~\hat{z}\\\end{split}\]

Space Group: 191

Point Group of Structure: \(6/mmm\)

Structure DOI: https://doi.org/10.1016/0022-5088(74)90037-X

Source: Inorganic Crystallographic Database #25364

MPB Epsilon Input File: Download

Gap Atlas for \(\varepsilon = 16\)

Gap Atlas for \(\varepsilon\) = 16 across filling fraction \(\phi\) and frequency \(\omega\).

Gap Atlas for \(\varepsilon = 14\)

Gap Atlas for \(\varepsilon\) = 14 across filling fraction \(\phi\) and frequency \(\omega\).

Gap between Bands 11-12

Below is the band structure and isosurface of hP3–Hg (Direct) at dielectric contrast \(\varepsilon = 16\), radius \(r = 0.26\) and filling fraction \(\phi = 0.146\).

Band Structure across first Brillouin Zone.

View along \(a_1\).
