hR12-B (Inverse)

hR12–B (Inverse)

Image of hR12–B (Inverse), generated by Vesta

Lattice Vectors:

\[\begin{split}a_1 &= ~\hat{x}\\ a_2 &= 0.5290308796~\hat{x} + 0.8486025739~\hat{y}\\ a_3 &= 0.5290308796~\hat{x} + 0.293608829~\hat{y} + 0.7961910474~\hat{z}\\\end{split}\]

Space Group: 166

Point Group of Structure: \(\bar{3}m\)

Structure DOI: https://doi.org/10.1107/S0365110X59001529

Source: Inorganic Crystallographic Database #26487

MPB Epsilon Input File: Download

Gap Atlas for \(\varepsilon = 16\)

Gap Atlas for \(\varepsilon\) = 16 across filling fraction \(\phi\) and frequency \(\omega\).

Gap Atlas for \(\varepsilon = 14\)

Gap Atlas for \(\varepsilon\) = 14 across filling fraction \(\phi\) and frequency \(\omega\).

Gap between Bands 7-8

Below is the band structure and isosurface of hR12–B (Inverse) at dielectric contrast \(\varepsilon = 16\), radius \(r = 0.24\) and filling fraction \(\phi = 0.25\).

Band Structure across first Brillouin Zone.

View along \(a_1\).
